Large-format tube-sheet dual-purpose Laser Cutting Machine

Collect
商品说明

Main features:

1. Independent research and development, tube and plate dual-purpose fiber laser cutting machine, to achieve a pipe, plate cutting equipment, greatly saving the cost space.

2. A wide range of processing, different diameter, length of pipe can be processed.

3. Using electric rotating shaft, speed adjustable, easy to operate, with low noise, high speed, high precision.

4. Can cut intersecting tangent, is a professional processing pipe, steel structure and pipe the best choice.

5. Material application: stainless steel, carbon steel, alloy steel, spring steel, copper plate, aluminum plate, gold, silver and other metal plate cutting

型号

MK-G3015X

MK-G4015X

MK-4020X

MK-6015X

MK-6020X

切割范围/Cutting Range(mm)

1500X3000

1500x4000

2000X4000

2000X6000

2500X6000

切割直径/Cutting Diameter(mm)

Ø20-200

切割长度/Cutting Length(mm)

3000

4000

4000

6000

6000

切割方管规格/Cutting Square Tube(mm)

20x20-140x140

X·Y轴定位精度/X·Y Axis Positioning Accuracy(mm)

±0.03

±0.03

±0.03

±0.03

±0.03

X·Y最大加速度/X·Y Max. Accelerationg(m/s2

140

140

140

140

140

W轴定位精度/W Axis Positioning Accuracy(mm)

15

15

15

15

15

激光功率/Laser Power

500/800/1000/1500/2000/3000/4000/6000
